Design of Microstrip Patch Antenna using for Wireless System

  • Ravinder Kaur Desh Bhagat University Mandi Gobindgarh
  • Ruchi * Desh Bhagat University Mandi Gobindgarh
DOI: https://doi.org/10.53555/eee.v3i3.268
Keywords: Wireless Communication, Antenna, Microstrip Patch Antenna, Feeding Method, MATLAB and CST, Microwave Studio software

Abstract

This paper presents the design and simulation results of a design to microstrip patch antenna using with two feeding techniques for Wireless (1.9 GHz) applications. The proposed antenna is designed on FR4 substrate with a thickness of 1.6 mm, permittivity of 4.4 and tangential loss of 0.025. The size of the antenna is 37.26 × 48 ×1.6 mm3 and has a Microstrip feed line and Inset feed line. The antenna has a low return loss and VSWR. Our aim to improve the return loss and VSWR using MATLAB and CST Microstrip Studio software and comparison of the MATLAB and CST Microstrip Studio software.

Downloads

Download data is not yet available.

Author Biographies

Ravinder Kaur, Desh Bhagat University Mandi Gobindgarh

M.Tech (ECE)

Ruchi *, Desh Bhagat University Mandi Gobindgarh

A.P. (ECE)

Published
2017-03-31
How to Cite
Kaur, R., & *, R. (2017). Design of Microstrip Patch Antenna using for Wireless System. IJRDO - Journal of Electrical And Electronics Engineering, 3(3), 10-14. https://doi.org/10.53555/eee.v3i3.268
Issue
Vol. 3 No. 3 (2017): IJRDO - Journal of Electrical And Electronics Engineering
